Bobbin Dyeing Machine ATC-DYE MBB01F

air-pad system – Steam heated – Material carrier for bobbins, fabrics, narrow fabrics , loose fibres, hanks, stripes and zipper bands dyeing is a HT / HP (4.8 bar 140°C) sample dyeing machine. Thanks to its suitable apparatus, it provides the opportunity to make small production and sample trials.

Technical Specifications
General MaterialCr-Ni Stainless Steel
Machine Capacity1-2 Bobbin
Max. Temperature140 ⁰C
Heating TypeResistance or Steam
Working Pressure3,5 Bar
Bath Ratio1:8/01:10
Kier Diameter220 mm
Kier Height560 mm
Additional Tank Capacity2 lt
Dosing Pumpmax. 2 Bar
ControlFull Otomatik Boyama Bilgisayarı
Power Supply380 V, 50 Hz
Total Power7,3 kW
Dimensions1070*920*1200 mm
